Cleans carriers, pallets, condensation filters of virtually all manufacturers from flux, condensate, oil, dust, grease

kolb AF30 is a state of the art immersion cleaning system with ClosedLoop water reprocessing. It cleans components of flux management systems (cooling units, filters, heat exchangers, containers/plates)* of virtually all manufacturers as well as lathe parts, milled parts, die cast components or other bulk good (with washing drum option) from flux, condensate, oil, dust, grease
using the economic and environmentally friendly AirFlow^{^®} technology.

*Up-to-date reflow-soldering systems as well as solar process ovens usually have flux management systems (cooling unit, filters, heat exchanges, containers/plates) which during operation will be subject to contamination (with flux/raisin). Thorough cleaning helps to regain proper functioning.

Highlights

Single-chamber system with automatic operation: cleaning, rinsing, drying
Average process time: 60 min
Loading and unloading in an empty process chamber (no contact to detergent)
Processes and service intervals PLC controlled
Event issuing and software control via touch screen
External cleaning of cyclones and oven tubings possible
Plug & work system (connect, fill, start)
Installation close to the production line possible; no special protection required

Technical data
Technology base	kolb AirFlow^®
Control system (Display size)	PLC - Eaton (7“)
Standard capacity (per process cycle)	Filters, condensation traps, carriers up to 1,300 x 450 x 590 mm
Process chamber dimensions	W 1300 mm • D 480 mm • H 590 mm
Max. stencil, carrier, washing frame size	H 1290 mm x W 500 mm
Circuits	2: Cleaning, Rinsing tap water / Rinsing DI-water (combined)
Volume Tank A	500 l • Cleaning
Volume Tank B/C	500 l • Rinsing tap water / Rinsing DI-water (combined)
Max. cleaning temperature	50 °C (122 °F)
Filtration	up to three stages - 1. Full flow coarse filter < 2 mm (0.08"), 2. Skimmer fine filtration for cleaning and rinsing circuit, 3. Oil skimmer for the cleaning circuit
Drying System	CTS HotSpeed warm air
Drying temperature range	approx. 40 - 55 °C (104 and 131 °F)
Power supply	400 V AC, 16 A, CEE plug / 3 Ph / 50 or 60 Hz
Power consumption	2 kW
Supply connection 1 (tap water)	1“
Supply connection 3 (Compressed Air)	12 mm (87 - 174 psi - 100 l / min)
Empty Weight	750 kg (1,654 lbs)
Footprint	2330 mm x 1540 mm (91.73″ x 60.63″)

Certifications

ENERSAVE certified

kolb cleaning systems are ENERSAVE certified for offering top performance and using less energy than any comparable competitor product.

WATERSAVE certified

The kolb technologies ClosedLoop and CrossLoop are WATERSAVE certified and save significantly water by recycling contaminated rinsing liquids.

EASOTECH certified

EASOTECH assures state of the art technology with the easiest possible operation of complex engineering performance and intelligent software design.

SAFEGAR certified

The 5-star SAFEGAR certificate ensures that all relevant safety and protective functions are included in the standard version of every kolb cleaning system.

Smart Factory ready / Standard

Smart Factory ready economy systems can be equipped with a basic traceability function and thus be easily integrated into industry 4.0 production environments.
